AP70P03NF Todos los transistores



AP70P03NF MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características


   Número de Parte: AP70P03NF
   Tipo de FET: MOSFET
   Polaridad de transistor: P

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 90 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 30 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 70 A
   Tjⓘ - Temperatura máxima de unión: 175 °C

CARACTERÍSTICAS ELÉCTRICAS


   trⓘ - Tiempo de subida: 40 nS
   Cossⓘ - Capacitancia de salida: 255 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.0072 Ohm
   Paquete / Cubierta: PDFN5X6-8L


 Búsqueda de reemplazo de AP70P03NF MOSFET

   - Selección ⓘ de transistores por parámetros



AP70P03NF Datasheet (PDF)

 ..1. Size:1611K  cn apm
 ap70p03nf.pdf pdf_icon

AP70P03NF

AP70P03NF -30V P-Channel Enhancement Mode MOSFET Description The AP70P03NF uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -30V I =-70 A DS DR

 7.1. Size:1663K  cn apm
 ap70p03d.pdf pdf_icon

AP70P03NF

AP70P03D -30V P-Channel Enhancement Mode MOSFET Description The AP70P03D uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -30V I =-70 A DS DR

 7.2. Size:1495K  cn apm
 ap70p03df.pdf pdf_icon

AP70P03NF

AP70P03DF -30V P-Channel Enhancement Mode MOSFET Description The AP70P03DF uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -30V I =-70A DS DR

 7.3. Size:1735K  cn apm
 ap70p03p ap70p03t.pdf pdf_icon

AP70P03NF

AP70P03PIT -30V P-Channel Enhancement Mode MOSFET Description The AP70P03P/T uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -30V I =-78A DS DR

MOSTRAR MÁS
