Número de Parte: 2N700A-18
Material: Ge
Polaridad de transistor: PNP
ESPECIFICACIONES MÁXIMAS
Disipación total del dispositivo (Pc): 0.075 W
Tensión colector-base (Vcb): 25 V
Tensión colector-emisor (Vce): 20 V
Corriente del colector DC máxima (Ic): 0.05 A
Temperatura operativa máxima (Tj): 100 °C
CARACTERÍSTICAS ELÉCTRICAS
Transición de frecuencia (fT): 400 MHz
Capacitancia de salida (Cc): 2 pF
Ganancia de corriente contínua (hFE): 4
Encapsulados: TO18
