AP9569GH-HF Specs and Replacement
Type Designator: AP9569GH-HF
Type of Transistor: MOSFET
Type of Control Channel: P
-Channel
Absolute Maximum Ratings
Pd ⓘ
- Maximum Power Dissipation: 26
W
|Vds|ⓘ - Maximum Drain-Source Voltage: 40
V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20
V
|Id| ⓘ - Maximum Drain Current: 14
A
Tj ⓘ - Maximum Junction Temperature: 150
°C
Electrical Characteristics
tr ⓘ - Rise Time: 20
nS
Cossⓘ -
Output Capacitance: 80
pF
Rds ⓘ - Maximum Drain-Source On-State Resistance: 0.09
Ohm
Package:
TO-252
-
MOSFET ⓘ Cross-Reference Search
