AP4608S MOSFET. Datasheet pdf. Equivalent
Type Designator: AP4608S
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Pdⓘ - Maximum Power Dissipation: 333 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 40 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
|Vgs(th)|ⓘ - Maximum Gate-Threshold Voltage: 5 V
|Id|ⓘ - Maximum Drain Current: 120 A
Tjⓘ - Maximum Junction Temperature: 175 °C
Qgⓘ - Total Gate Charge: 170 nC
trⓘ - Rise Time: 75 nS
Cossⓘ - Output Capacitance: 1730 pF
Rdsⓘ - Maximum Drain-Source On-State Resistance: 0.0017 Ohm
Package: TO263
AP4608S Transistor Equivalent Substitute - MOSFET Cross-Reference Search
AP4608S Datasheet (PDF)
ap4608s.pdf
AP4608SHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 1.7m Fast Switching CharacteristicGG RoHS Compliant & Halogen-FreeSSDescriptionAP4604 series are from Advanced Power innovated designAP4608 series are from Advanced Power innovated des
ap4608p.pdf
AP4608PHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 1.7m Fast Switching Characteristic ID3 330AGG RoHS Compliant & Halogen-FreeSSDescriptionAP4604 series are from Advanced Power innovated designAP4608 series are from Advanced Power inno
ap4604p.pdf
AP4604PHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 3.7m Fast Switching Characteristic ID3 140AGG RoHS Compliant & Halogen-FreeSSDescriptionAP4604 series are from Advanced Power innovated designAP4604 series are from Advanced Power inno
ap4606p.pdf
AP4606PHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 3.7m Fast Switching Characteristic ID3 125AG RoHS Compliant & Halogen-FreeSDescriptionAP4606 series are from Advanced Power innovated designand silicon process technology to achieve the lowes
ap4604ai.pdf
AP4604AIHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 2.5m Fast Switching Characteristic ID 85AGG RoHS Compliant & Halogen-FreeSSDescriptionAP4604 seriesare fromAdvanced Power innovated designAP4604Aseries arefrom AdvancedPower innovated
ap4604i.pdf
AP4604IHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 2.5m Fast Switching Characteristic ID 100AGG RoHS Compliant & Halogen-FreeSSDescriptionAP4604 series are from Advanced Power innovated designAP4604 series are from Advanced Power innov
ap4604in.pdf
AP4604INHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement D BVDSS 40V Ultra-low On-resistance RDS(ON) 2.5m Fast Switching Characteristic ID 100AGG RoHS Compliant & Halogen-FreeSSDescriptionAP4604 series are from Advanced Power innovated designAP4604 series are from Advanced Power inno
ap4606cs.pdf
AP4606CS / Descriptions SOP-8 MOS Complementary Enhancement MOSFET in a SOP-8 Plastic Package. / Features N-channel P-channelVDS(V)=30V VDS(V)=-30V ID=6.9A ID=-6A RDS(ON)
