IPI65R099C6 Specs and Replacement
Type Designator: IPI65R099C6
Type of Transistor: MOSFET
Type of Control Channel: N-Channel
Absolute Maximum Ratings
Pd ⓘ
- Maximum Power Dissipation: 278 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 650 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
|Id| ⓘ - Maximum Drain Current: 38 A
Tj ⓘ - Maximum Junction Temperature: 150 °C
Electrical Characteristics
tr ⓘ - Rise Time: 9 nS
Cossⓘ -
Output Capacitance: 142 pF
RDSonⓘ - Maximum Drain-Source On-State Resistance: 0.099 Ohm
Package: TO-262
- MOSFET ⓘ Cross-Reference Search
IPI65R099C6 datasheet
..1. Size:3785K infineon
ipa65r099c6 ipb65r099c6 ipi65r099c6 ipp65r099c6 ipw65r099c6.pdf
MOSFET Metal Oxide Semiconductor Field Effect Transistor CoolMOS C6 650V 650V CoolMOS C6 Power Transistor IPx65R099C6 Data Sheet Rev. 2.0 Final Industrial & Multimarket 650V CoolMOS C6 Power Transistor IPW65R099C6, IPB65R099C6, IPP65R099C6 IPA65R099C6, IPI65R099C6 TO-247 D PAK TO-220 1 Description CoolMOS is a revolutionary technology for high voltage power MOSFETs... See More ⇒
..2. Size:3828K infineon
ipw65r099c6 ipb65r099c6 ipp65r099c6 ipa65r099c6 ipi65r099c6.pdf
MOSFET Metal Oxide Semiconductor Field Effect Transistor CoolMOS C6 650V 650V CoolMOS C6 Power Transistor IPx65R099C6 Data Sheet Rev. 2.0 Final Industrial & Multimarket 650V CoolMOS C6 Power Transistor IPW65R099C6, IPB65R099C6, IPP65R099C6 IPA65R099C6, IPI65R099C6 TO-247 D PAK TO-220 1 Description CoolMOS is a revolutionary technology for high voltage power MOSFETs... See More ⇒
..3. Size:286K inchange semiconductor
ipi65r099c6.pdf
isc N-Channel MOSFET Transistor IPI65R099C6 FEATURES Static drain-source on-resistance RDS(on) 0.099 Enhancement mode Fast Switching Speed 100% avalanche tested Minimum Lot-to-Lot variations for robust device performance and reliable operation DESCRIPTION Provide all benefits of a fast switching SJ MOSFET while not sacrificing ease of use ABSOLUTE MAXIMUM RA... See More ⇒
