All MOSFET. JMTP260N03D Datasheet



JMTP260N03D Datasheet and Replacement


   Type Designator: JMTP260N03D
   Type of Transistor: MOSFET
   Type of Control Channel: N -Channel
   Pd ⓘ - Maximum Power Dissipation: 1.8 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 30 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 12 V
   |Id| ⓘ - Maximum Drain Current: 8 A
   Tj ⓘ - Maximum Junction Temperature: 150 °C
   tr ⓘ - Rise Time: 11 nS
   Cossⓘ - Output Capacitance: 65 pF
   Rds ⓘ - Maximum Drain-Source On-State Resistance: 0.023 Ohm
   Package: SOP8


 JMTP260N03D substitution

   - MOSFET ⓘ Cross-Reference Search



JMTP260N03D Datasheet (PDF)

 ..1. Size:686K  jiejie micro
 jmtp260n03d.pdf pdf_icon

JMTP260N03D

JMTP260N03DDescriptionJMT Dual N-channel Enhancement Mode Power MOSFETFeaturesApplications 30V, 8A Load SwitchRDS(ON)

 9.1. Size:660K  jiejie micro
 jmtp240c03d.pdf pdf_icon

JMTP260N03D

JMTP240C03D Description JMT N And P-Channel Enhancement Mode MOSFET Features Application N-Channel: 30V, 9A Battery Protection R

 9.2. Size:733K  jiejie micro
 jmtp240n03d.pdf pdf_icon

JMTP260N03D

JMTP240N03DDescriptionJMT Dual N-channel Enhancement Mode Power MOSFETFeatures Applications 30V, 9A Load SwitchRDS(ON)

 9.3. Size:514K  jiejie micro
 jmtp230c04d.pdf pdf_icon

JMTP260N03D

JMTP230C04DDescriptionJMT N And P-Channel Enhancement Mode MOSFETFeatures Application N-Channel: 40V, 8A Battery ProtectionR

SHOW MORE

Datasheet: JMTP160P03D , JMTP170C04D , JMTP170N06A , JMTP170N06D , JMTP230C04D , JMTP240C03D , JMTP240N03D , JMTP250P03A , 2N7002 , JMTP3008A , JMTP3010D , JMTP330N06D , JMSL0601AG , JMSL0601AGQ , JMSL0601BG , JMSL0601BGQ , JMSL0601TG .
