All MOSFET. ATM1205PSI Datasheet



ATM1205PSI Datasheet and Replacement


   Type Designator: ATM1205PSI
   Type of Transistor: MOSFET
   Type of Control Channel: P -Channel
   Pd ⓘ - Maximum Power Dissipation: 0.47 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 12 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 12 V
   |Id| ⓘ - Maximum Drain Current: 1.7 A
   Tj ⓘ - Maximum Junction Temperature: 150 °C
   tr ⓘ - Rise Time: 19.8 nS
   Cossⓘ - Output Capacitance: 172 pF
   Rds ⓘ - Maximum Drain-Source On-State Resistance: 0.1 Ohm
   Package: SOT323


 ATM1205PSI substitution

   - MOSFET ⓘ Cross-Reference Search



ATM1205PSI Datasheet (PDF)

 ..1. Size:1018K  agertech
 atm1205psi.pdf pdf_icon

ATM1205PSI

ATM1205PSIP-Channel Enhancement Mode Field Effect TransistorDescriptionFeatureThe ATM1205PSI uses advanced trenchtechnology V (V) = -12VDSto provide excellent R , low gate charge andDS(ON) I = -1.7 A (V = -4.5V)D GSoperation with gate voltages as low as 1.8V. This R
