10N65A/10N65AFGOFORDDescription Features VDSS RDS(ON) ID @10V (typ) 10A650V 0.72 Fast switching 100% avalanche tested Improved dv/dt capability Application Active power factor correction Uninterruptible Power Supply (UPS) Electronic lamp ballasts Absolute Maximum Ratings TC=25 unless otherwise specified Symbol Parameter TO-220 TO-220F Units V Drain-Source Voltage 650 V DSSV Gate-Source Voltage 30 V GSSTC = 25 10 10* A I Continuous Drain Current DT = 100 6.23 6.23* A C I Pulsed Drain Current note1 40 40* A DMEAS Single Pulsed Avalanche Energy note2 280 mJ dv/dt Peak Diode Recovery Energy note3 4.5 V/ns Power Dissipation TC = 25 156 50 W P DLinear Derating Factor T > 25 1.25 0.4 W/ CR Thermal Resistance, Junction to Case 0.8 2.5 /W JCT , T Operating and S
