UNISONIC TECHNOLOGIES CO., LTD 10N65Z Power MOSFET 10A, 650V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 10N65Z is a high voltage and high current power MOSFET, designed to have better characteristics, such as fast switching time, low gate charge, low on-state resistance and a high rugged avalanche characteristics. This power MOSFET is usually used at high speed switching applications in power supplies, PWMmotor controls, high efficient DC to DC converters and bridge circuits. FEATURES * RDS(ON) =0.95@ VGS=10V, ID=4.75A * Low gate charge ( typical 44 nC) * Low Crss ( typical 18 pF) * Fast switching * 100% avalanche tested * Improved dv/dt capability SYMBOL ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3 10N65ZL-TF1-T 10N65ZG-TF1-T TO-220F1 G D S TubeNote: Pin Assignment
