Скачать даташит для 2n2222au:

SEMICONDUCTOR2N2222AUTECHNICAL DATAGeneral Purpose TransistorNPN SiliconThese transistors are designed for general purpose amplifierapplications. They are housed in the SC-323/SC-70 package which 3is designed for low power surface mount applications.Features 12compliance with RoHS requirements. We declare that the material of product SC-70 / SOT 323 ORDERING INFORMATIONCOLLECTORDevice Maring Shipping33000 / Tape & Reel 2N2222AU P11BASE2EMITTERMAXIMUM RATINGS (TA = 25C)Rating Symbol Max UnitCollector-Emitter Voltage VCEO 40 VdcCollector-Base Voltage VCBO 75 VdcEmitter-Base Voltage VEBO 6.0 VdcCollector Current - Continuous IC 600 mAdcTHERMAL CHARACTERISTICSCharacteristic Symbol Max UnitTotal Device Dissipation (Note 1) PD 150 mWTA = 25CThermal Resistance, R 833 C/WJAJunction-to-AmbientOperating and
