TECHNICAL DATA SHEET 6 Lake Street, Lawrence, MA 01841 6 Lake Street, Lawrence, MA 01841 Gort Road Business Park, Ennis, Co. Clare, Ireland 1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803 Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298 Website: http://www.microsemi.com NPN SILICON DUAL TRANSISTOR Qualified per MIL-PRF-19500 /355 DEVICES LEVELS 2N2919 2N2919L 2N2919U JAN2N2920 2N2920L 2N2920U JANTXJANTVJANSABSOLUTE MAXIMUM RATINGS (TC = +25C unless otherwise noted) Parameters / Test Conditions Symbol Value Unit Collector-Emitter Voltage VCEO 60 VdcCollector-Base Voltage VCBO 70 VdcEmitter-Base Voltage VEBO 6.0 VdcCollector Current IC 30 mAdcOne Both Section 1 Sections 2 PT 200Total Power Dissipation @ TA = +25C 350 mWTO-78 Operating & Storage Junction Temperature Range TJ, Tstg -65 to +200 C NOTES: 1. Derate linearly 1.143
