2N3767SMD05MECHANICAL DATADimensions in mm (inches)7.54 (0.296)NPN BIPOLAR TRANSISTOR 0.76 (0.030)min.IN A CERAMIC SURFACE MOUNT3.175 (0.125) 2.41 (0.095) 2.41 (0.095) Max. 0.127 (0.005)PACKAGE FORHIGH REL APPLICATIONS1 32FEATURES HIGH VOLTAGE 0.127 (0.005)16 PLCS 0.127 (0.005) 0.50(0.020) FAST SWITCHING0.50 (0.020)max.7.26 (0.286) CERAMIC SURFACE MOUNT PACKAGE SCREENING OPTIONS AVAILABLESMD05 (TO-276AA)Underside ViewPIN 1 Base PIN 2 Collector PIN 3 EmitterABSOLUTE MAXIMUM RATINGS (Tcase = 25C unless otherwise stated)VCBO Collector Base Voltage (IE = 0) 100VVCEO Collector Emitter Voltage (IB = 0) 80VVEBO Emiiter Base Voltage (IB = 0) 6VIB Base Current 2AIC Collector Current 4ATJ ,TSTG Operating and Storage Junction Temperature Range 55 to +150CPD Total Device Dissipation
