2N4910X2N4911X2N4912XMECHANICAL DATANPN EPITAXIALDimensions in mm (inches)POWER TRANSISTOR IN TO66 HERMETIC PACKAGE6.35 (0.250)8.64 (0.340)3.68(0.145) rad.3.61 (0.142)max.3.86 (0.145)rad.APPLICATIONS SCREENING OPTIONS AVAILABE1 2 TO66 PACKAGE1.27 (0.050)1.91 (0.750)4.83 (0.190)5.33 (0.210)9.14 (0.360)min.TO66 Metal Package.PIN 1 = BASE PIN 2 = EMITTER CASE = COLLECTORABSOLUTE MAXIMUM RATINGS(Tcase = 25C unless otherwise stated)2N4910X 2N4911X 2N4912XV(BR)CBO Collector Base Breakdown Voltage 40V 60V 80VV(BR)CEO Collector Emitter Breakdown Voltage 40V 60V 80VV(BR)EBO Emitter Base Breakdown Voltage 5VIC Continuous Collector Current 4AIB Base Current 1APD Total Power Dissipation 25WTC Operating Case Temperature Range 65 to +200CTstg Storage Temperature Range 65 to +200CR JC The
