2N5015X 2N5015SX MECHANICAL DATA HIGH VOLTAGE Dimensions in mm (inches) 8.51 (0.34)9.40 (0.37) SILICON EPITAXIAL 7.75 (0.305)8.51 (0.335)NPN TRANSISTOR6.10 (0.240)6.60 (0.260)0.89max.(0.035)38.00(1.5) FEATURES min. 0.41 (0.016)0.53 (0.021) SILICON PLANAR EPITAXIAL NPN TRANSISTOR dia. HIGH BREAKDOWN VOLTAGE LOW SATURATION VOLTAGE 5.08 (0.200)typ. HERMETIC TO5 or TO39 (S Suffix) PACKAGE HI-RELIABILITY SCREENING OPTIONS AVAILABLE2.542(0.100)1 3APPLICATIONS 0.74 (0.029)1.14 (0.045)For high reliability general purpose high voltage switching 0.71 (0.028)0.86 (0.034)and linear applications requiring small size and low weight devices. 45TO5 (TO-205AA) Underside View PIN 1 Emitter PIN 2 Base PIN 3 Collector ABSOLUTE MAXIMUM RATINGS TCASE = 25C unless otherwise stated V
