Скачать даташит для 2n5484_mmbf5484:

2N5484 MMBF54842N5485 MMBF54852N5486 MMBF5486GSG TO-92SSOT-23 DDMark: 6B / 6M / 6HNOTE: Source & Drain are interchangeableN-Channel RF AmplifierThis device is designed primarily for electronic switchingapplications such as low On Resistance analog switching.Sourced from Process 50.Absolute Maximum Ratings* TA = 25C unless otherwise notedSymbol Parameter Value UnitsVDG Drain-Gate Voltage 25 VVGS Gate-Source Voltage - 25 VIGF Forward Gate Current 10 mAOperating and Storage Junction Temperature Range -55 to +150 CTJ ,Tstg *These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle opera
