2PA1576PNP general-purpose transistorRev. 06 17 November 2009 Product data sheet1. Product profile1.1 General descriptionPNP transistor in a SOT323 (SC-70) plastic package. The NPN complement is 2PC4081.1.2 Features Low current (max. 150 mA) Low voltage (max. 50 V) Low collector capacitance (typ. 2.5 pF)1.3 Applications General-purpose switching and amplification2. Pinning informationTable 1. PinningPin Description Simplified outline Symbol1base3 32emitter3 collector1122sym0133. Ordering informationTable 2. Ordering informationType number Package Name Description Version2PA1576Q SC-70 plastic surface mounted package; 3 leads SOT3232PA1576R2PA1576S2PA1576NXP SemiconductorsPNP general-purpose transistor4. MarkingTable 3. Marking codesType number Marking code[1]2PA1576Q F*Q2PA1576R F*R2PA1576S F*S[1] * = -
