2PA1774xMB series40 V, 100 mA PNP general-purpose transistorsRev. 1 23 March 2012 Product data sheet1. Product profile1.1 General descriptionPNP general-purpose transistors in a leadless ultra small DFN1006B-3 (SOT883B) Surface-Mounted Device (SMD) plastic package.Table 1. Product overviewType number Package NPN complementNexperia JEITA JEDEC2PA1774QMB SOT883B - - 2PC4617QMB2PA1774RMB SOT883B - - 2PC4617RMB2PA1774SMB SOT883B - - -1.2 Features and benefits Leadless ultra small SMD plastic Power dissipation comparable to SOT23package Low package height of 0.37 mm AEC-Q101 qualified1.3 Applications General-purpose switching and amplification Mobile applications1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - 40 VIC collect
