2PD601ARL; 2PD601ASL50 V, 100 mA NPN general-purpose transistorsRev. 01 6 November 2008 Product data sheet1. Product profile1.1 General descriptionNPN general-purpose transistors in a small SOT23 (TO-236AB) Surface-MountedDevice (SMD) plastic package.Table 1. Product overviewType number[1] Package PNP complementNexperia JEDEC2PD601ARL SOT23 TO-236AB 2PB709ARL2PD601ASL 2PB709ASL2PD601ARL/DG SOT23 TO-236AB 2PB709ARL/DG2PD601ASL/DG 2PB709ASL/DG[1] /DG: halogen-free.1.2 Features General-purpose transistors Two current gain selections AEC-Q101 qualified Small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - 50 VIC collector current - - 100 mAhFE DC current gain VC
