Power Transistors2SA1096, 2SA1096ASilicon PNP epitaxial planar typeFor low-frequency power amplificationUnit: mm8.0+0.50.13.20.2Complementary to 2SC2497, 2SC2497A 3.160.1 Features Output of 5 W can be obtained by a complementary pair with2SC2497 and 2SC2497A TO-126B package which requires no insulation plate for installa-tion to the heat sink Absolute Maximum Ratings Ta = 25CParameter Symbol Rating Unit0.750.10.50.1Collector-base voltage (Emitter open) VCBO -70 V0.50.1 1.760.14.60.22.30.22SA1096 VCEO -50 VCollector-emitter voltage1: Emitter(Base open)2SA1096A -60 2: Collector1 2 33: BaseEmitter-base voltage (Collector open) VEBO -5 VTO-126B-A1 PackageCollector current IC -2 APeak collector current ICP -3 ACollector power dissipation PC 1.2 WJunction temperature Tj 150 CStorage
