2SA1213-89 Plastic-Encapsulate TransistorsSOTTRANSISTOR (PNP) SOT-89 FEATURES Small Flat Package1. BASE Power Amplifier and Switching Applications 2. COLLECTOR Low Saturation Voltage High Speed Switching Time3. EMITTER Pb-Free package is available RoHS product for packing code suffix "G" Halogen free product for packing code suffix "H" MAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter Value Unit VCBO Collector-Base Voltage -50 V VCEO Collector-Emitter Voltage -50 V VEBO Emitter-Base Voltage -5 V IC Collector Current -2 A PC Collector Power Dissipation 500 mW RJA Thermal Resistance From Junction To Ambient 250 /W Tj Junction Temperature 150 Tstg Storage Temperature -55~+150 ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified) Parameter Symbol Test conditions Min Typ Max Unit Coll
