Ordering number:ENN1048CPNP/NPN Epitaxial Planar Silicon Transistors2SA1252/2SC3134High VEBO, AF Amp ApplicationsFeatures Package Dimensions High VEBO.unit:mm Wide ASO and high durability against breakdown.2018B[2SA1252/2SC3134]0.40.1630 to 0.11 0.95 0.95 21.92.91 : Base2 : Emitter( ) : 2SA1252 3 : CollectorSANYO : CPSpecificationsAbsolute Maximum Ratings at Ta = 25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO ()60 VCollector-to-Emitter Voltage VCEO ()50 VEmitter-to-Base Voltage VEBO ()15 VCollector Current IC ()150 mACollector Current (Pulse) ICP ()300 mACollector Dissipation PC 200 mWJunction Temperature Tj 125 CStorage Temperature Tstg 55 to +125 CElectrical Characteristics at Ta = 25CRatingsParameter Symbol Conditions Unitmin typ maxCollector Cutoff Cur
