Скачать даташит для 2sa1587:

2SA1587 TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT process) 2SA1587 Audio Frequency General Purpose Amplifier Applications Unit: mm High voltage: VCEO = -120 V Excellent h linearity: h (I = -0.1 mA)/h (I = -2 mA) FE FE C FE C = 0.95 (typ.) High hFE: hFE = 200~700 Low noise: NF = 1dB (typ.), 10dB (max) Complementary to 2SC4117 Small package Maximum Ratings (Ta == 25C) ==Characteristics Symbol Rating UnitCollector-base voltage VCBO -120 VCollector-emitter voltage VCEO -120 VEmitter-base voltage VEBO -5 VCollector current IC -100 mABase current IB -20 mAJEDEC Collector power dissipation PC 100 mWJEITA SC-70Junction temperature Tj 125 CTOSHIBA 2-2E1AStorage temperature range Tstg -55~125 CWeight: 0.006 g (typ.) Electrical Characteristics (Ta == 25C) ==Characteristics Symbol Tes
