JMnic Product Specification Silicon PNP Power Transistors 2SA489 DESCRIPTION With TO-220 package Low collector saturation voltage Short switching time APPLICATIONS Various inductance lamp drivers for electrical equipment Inverters;converters Power amplification Switching regulator ,driver PINNING PIN DESCRIPTION1 Emitter Collector;connected to 2 mounting base Fig.1 simplified outline (TO-220) and symbol3 BaseAbsolute maximum ratings(Ta=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter -70 V VCEO Collector-emitter voltage Open base -60 V VEBO Emitter-base voltage Open collector -5 V IC Collector current -4 A PC Collector power dissipation TC=25 30 W Tj Junction temperature 150 Tstg Storage temperature -55~150 JMnic Product Specification Silicon PNP Power Transistors
