Скачать даташит для 2sb566:

2SB566(K), 2SB566A(K)Silicon PNP Triple DiffusedApplicationLow frequency power amplifier power switching complementary pair with 2SD476(K) and 2SD476A(K)OutlineTO-220AB1. Base2. Collector(Flange)13. Emitter23Absolute Maximum Ratings (Ta = 25C)RatingsItem Symbol 2SB566(K) 2SB566A(K) UnitCollector to base voltage VCBO 70 70 VCollector to emitter voltage VCEO 50 60 VEmitter to base voltage VEBO 5 5 VCollector current IC 4 4 ACollector peak current IC(peak) 8 8 ACollector power dissipation PC*1 40 40 WJunction temperature Tj 150 150 CStorage temperature Tstg 55 to +150 55 to +150 CNote: 1. Value at TC = 25 C.2SB566(K), 2SB566A(K)Electrical Characteristics (Ta = 25C)2SB566(K) 2SB566A(K)Item Symbol Min Typ Max Min Typ Max Unit Test conditionsCollector to base V(BR)CBO 70
