2SC1213, 2SC1213A NPN General Purpose Transistor Elektronische Bauelemente RoHS Compliant Product A suffix of -C specifies halogen and lead free FEATURES TO-92 Low frequency amplifier G H Complementary pair with 2SA673 and 2SA673A 1Emitter 1112Collector 2223Base 333CLASSIFICATION OF hFE(1) JA DProduct-Rank 2SC1213-B 2SC1213-C 2SC1213-D Millimeter REF. Min. Max. BA 4.40 4.70 Product-Rank 2SC1213A-B 2SC1213A-C 2SC1213A-D B 4.30 4.70 C 12.70 - KRange 60~120 100~200 160~320 D 3.30 3.81 E 0.36 0.56 F 0.36 0.51 G 1.27 TYP. E C FH 1.10 - J 2.42 2.66 K 0.36 0.76 Collector 3 2 Base 1 Emitter ABSOLUTE MAXIMUM RATINGS (TA = 25C unless otherwise specified) Parameter Symbol Rating Unit 2SC1213 35 Collector to Base Voltage VCBO V 2SC1213A 50 2SC1213 35 Collector to Emitter Volta
