2SC1383/2SC1384 TO-92MOD Transistor (NPN)1.EMITTER TO-92MOD2.COLLECTOR 1 23.BASE 3 Features5.800 Low collector to emitter saturation voltage VCE(sat). 6.200 Complementary pair with 2SA0683 and 2SA0684. 8.4008.800MAXIMUM RATINGS (TA=25 unless otherwise noted) 0.9001.100Symbol Parameter 2SC1383 2SC1384 Units0.4000.600VCBO Collector-Base Voltage 30 60 V 13.800VCEO Collector-Emitter Voltage 25 50 V 14.200VEBO Emitter-Base Voltage 5 V IC Collector Current Continuous 1 A 1.500 TYP2.900 Dimensions in inches and (millimeters)PC Collector Power Dissipation 1 W 3.1000.000 1.600TJ Junction Temperature 150 0.3800.4004.700Tstg Storage Temperature -55-150 0.5005.100 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) 1.7302.0304.000 Parameter Symbol Test conditions MIN TYP MAX UNIT
