2SC2757TRANSISTOR (NPN)FEATURES SOT-23 AM/FM Amplifier, Local Oscillator of FM/VHF Tuner High Current Gain Bandwidth Product fT=1.1 GHz (Typ) 1BASE 2EMITTER 3COLLECTOR MARKING T33MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value Units VCBO Collector-Base Voltage 30 V VCEO Collector-Emitter Voltage 15 V VEBO Emitter-Base Voltage 5 V IC Collector Current -Continuous 50 mA PC Collector Power Dissipation 150 mW Tj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNITIC= 100A, IE=0 Collector-base breakdown voltage V(BR)CBO 30 V Collector-emitter breakdown voltage V(BR)CEO IC= 1mA, IB=0 15 V IE=100A, IC=0 Emitter-base breakdown voltage V(BR)EBO 5 V A Collector cut-
