SMD Type TransistorsNPN Transistors2SC3134SOT-23Unit: mm+0.12.9 -0.1+0.10.4-0.13 Features High VEBO. Wide ASO and high durability against breakdown.1 2 Complementary to 2SA1252+0.1+0.050.95 -0.1 0.1 -0.01+0.11.9 -0.11.Base2.Emitter3.collector Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Collector - Base Voltage VCBO 60 Collector - Emitter Voltage VCEO 50 V Emitter - Base Voltage VEBO 15 Collector Current - Continuous IC 150mA Collector Current - Pulse ICP 300 Collector Power Dissipation PC 200 mW Junction Temperature TJ 125 Storage Temperature Range Tstg -55 to 125 Electrical Characteristics Ta = 25Parameter Symbol Test Conditions Min Typ Max Unit Collector- base breakdown voltage VCBO Ic= 100 A IE= 0 60 Collector- emitter breakdown voltage VCEO Ic= 1 mA IB
