Ordering number : ENA0411A2SC6095Bipolar Transistorhttp://onsemi.com( )80V, 2.5A, Low VCE sat , NPN Single PCPApplicaitons DC / DC converter, relay drivers, lamp drivers, motor drivers, inverterFeatures Adoption of FBET, MBIT process Large current capacity Low collector-to-emitter saturation voltage High-speed switching High allowable power dissipationSpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO 120 VVCES 120 VCollector-to-Emitter VoltageVCEO 80 VEmitter-to-Base Voltage VEBO 6.5 VCollector Current IC 2.5 ACollector Current (Pulse) ICP 4 A Continued on next page.Package Dimensions Product & Package Informationunit : mm (typ) Package : PCP7007B-004 JEITA, JEDEC : SC-62, SOT-89, TO-243 Minimum Packing Quantity : 1,000 pcs
