2SC6114 Transistors Small signal low frequency amplifier (50V, 100mA) 2SC6114 Applications VMN3Small signal low frequency amplifier Features 0.220.16(3)1) Low Cob. Cob=2.0pF (Typ.) 2) Complements the 2SA2199. (1) (2) Structure 0.370.170.35NPN silicon epitaxial 0.6planar transistor (1) Base(2) EmitterAbbreviated symbol : N(3) Collector Dimensions (Unit : mm) Absolute maximum (Ta=25C) Parameter Symbol Limits UnitCollector-base voltage VCBO 50 VCollector-emitter voltage VCEO 50 VEmitter-base voltage VEBO 5 VIC 100Collector current mA1ICP 2002Power dissipation PD 150 mWJunction temperatureTj 150 CRange of storage temperatureTstg -55 to +150 C1 Pw=1ms Single pulse2 Each terminal mounted on a recommended land1/30.11.00.10.82SC6114 Transistors Electrical characteristics
