2SC6142 TOSHIBA Transistor Silicon NPN Triple Diffused Type 2SC6142 Unit: mm High Voltage Switching Applications Switching Regulator Applications DC-DC Converter Applications MAX Excellent switching times: tf = 0.15 s (typ.) High collector breakdown voltage: VCES = 800 V, VCEO = 375 V MAX Absolute Maximum Ratings (Ta = 25C) Characteristics Symbol Rating Unit MAXCollector-base voltage VCBO 800 V1 MAXVCES 800 V Collector-emitter voltage 1. BASE VCEO 375 V 2. COLLECTOR Emitter-base voltage VEBO 8 V 3. EMITTER DC IC 1.5 Collector current A JEDEC Pulse ICP 3Base current IB 0.75 AJEITA Collector power di
