Product specification Silicon Epitaxial Planar Transistor 2SC945 FEATURES Pb High voltage and high current. Lead-free Excellent h linearity. FE Low noise. APPLICATIONS Audio frequency amplifier. SOT-23 ORDERING INFORMATION Type No. Marking Package Code 2SC945 CR SOT-23 : none is for Lead Free package; G is for Halogen Free package. MAXIMUM RATING @ Ta=25 unless otherwise specified Symbol Parameter Value Units Collector-Base Voltage V 60 V CBO Collector-Emitter Voltage V 50 V CEO Emitter-Base Voltage V 5 V EBO Collector Current -Continuous I 100 mA C Collector Dissipation P 200 mW C Junction and Storage Temperature T T -55 to +150 j, stg STM0072A www.gmesemi.com 1 Product specification Silicon Epitaxial Planar Transistor 2SC945 ELECTRICAL CHARACTERISTICS @ Ta=25
