www.DataSheet.co.krOrdering number : EN86232SK3094SANYO SemiconductorsDATA SHEETN-Channel Silicon MOSFETGeneral-Purpose Switching Device2SK3094ApplicationsFeatures High-speed switching. Low ON-resistance. 15V drive.SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitDrain-to-Source Voltage VDSS 400 VGate-to-Source Voltage VGSS 30 VDrain Current (DC) ID 5.5 ADrain Current (Pulse) IDP 22 AAllowable Power Dissipation PD Tc=25C55 WChannel Temperature Tch 150 CStorage Temperature Tstg --55 to +150 CElectrical Characteristics at Ta=25CRatingsParameter Symbol Conditions Unitmin typ maxDrain-to-Source Breakdown Voltage V(BR)DSS ID=1mA, VGS=0V 400 VZero-Gate Voltage Drain Current IDSS VDS=320V, VGS=0V 1.0 mAGate-to-Source Leakage Current IGSS VGS= 30V, VDS=0V 100 nACutoff Vo
