2SK3694-01L,S,SJ200305FUJI POWER MOSFETN-CHANNEL SILICON POWER MOSFETSuper FAP-G Series Outline Drawings [mm]T-PackFeaturesHigh speed switchingLow on-resistanceNo secondary breadownLow driving powerAvalanche-proofP4ApplicationsSwitching regulatorsUPS (Uninterruptible Power Supply)DC-DC convertersMaximum ratings and characteristicAbsolute maximum ratings(Tc=25C unless otherwise specified)Item Symbol Ratings UnitDrain-source voltage VDS 450 VVDSX *5 450 V Equivalent circuit schematicContinuous drain current ID 17 APulsed drain current ID(puls] 68 ADrain(D)Gate-source voltage VGS 30 VRepetitive or non-repetitive IAR *2 17 AMaximum Avalanche Energy EAS *1 221.9 mJMaximum Drain-Source dV/dt dVDS/dt *4 20 kV/sGate(G)Peak Diode Recovery dV/dt dV/dt *3 5kV/sMax. power dissipation PD Ta=25C 1.67W Source(S)Tc=25
