Скачать даташит для 2sk3696-01mr:

2SK3696-01MR200309FUJI POWER MOSFETN-CHANNEL SILICON POWER MOSFETSuper FAP-G SeriesOutline Drawings [mm]FeaturesTO-220F High speed switching Low on-resistance No secondary breadown Low driving power Avalanche-proof Applications Switching regulators DC-DC converters UPS (Uninterruptible Power Supply)Maximum ratings and characteristicAbsolute maximum ratings(Tc=25C unless otherwise specified)Item Symbol Ratings Unit Remarks VDrain-source voltage VDS 500 AContinuous drain current ID 13 APulsed drain current ID(puls] 52Gate-source voltage VGS 30 VNon-Repetitive IAS 13 A
