2SK3697-01N-CHANNEL SILICON POWER MOSFET200407Outline Drawings (mm)FUJI POWER MOSFETSuper FAP-G SeriesFeatures High speed switching Low on-resistance No secondary breakdown Low driving power Avalanche-proof Applications Switching regulators DC-DC converters UPS (Uninterruptible Power Supply)Maximum ratings and characteristicAbsolute maximum ratings(Tc=25C unless otherwise specified)Item Symbol Ratings Unit RemarksDrain-source voltage VDS 600 VVDSX 600 VVGS=-30VContinuous Drain Current ID 42 A2.7 ATa=25CEquivalent circuit schematicPulsed Drain Current ID(puls] 168 ADrain(D)Gate-Source Voltage VGS 30 V
