AP05G120NSW-HFHalogen-Free ProductAdvanced Power N-CHANNEL INSULATED GATEElectronics Corp. BIPOLAR TRANSISTOR WITH FRD.Features VCES 1200V High Speed Switching IC 10.5A NPT Technology RoHS Compliant & Halogen-FreeGCTO-3PEAbsolute Maximum RatingsSymbol Parameter Rating UnitsVCES Collector-Emitter Voltage 1200 VVGE Gate-Emitter Voltage +30 VIC@TC=25 Collector Current 21 AIC@TC=100 Collector Current 10.5 AICM Pulsed Collector Current1 42 AIF@TC=100 Diode Forward Current 8 AIFM Diode Pulse Forward Current 40 APD@TC=25 Maximum Power Dissipation 125 W TSTG Storage Temperature Range -55 to 150 TJ Operating Junction Temperature Range -55 to 150 TL Maximum Lead Temp. for Soldering Purposes 300 , 1/8" from case for 5 seconds .Notes:1.Pulse width limited by max . junction temperature .Thermal DataSymbol Para
