TYPICAL PERFORMANCE CURVESAPT15GN120BD_SDQ1(G)APT15GN120BDQ1 APT15GN120SDQ1 APT15GN120BDQ1(G) APT15GN120SDQ1(G)1200V *G Denotes RoHS Compliant, Pb Free Terminal Finish.Utilizing the latest Field Stop and Trench Gate technologies, these IGBT's have ultra (B)low VCE(ON) and are ideal for low frequency applications that require absolute minimum conduction loss. Easy paralleling is a result of very tight parameter distribution and a D3PAKslightly positive VCE(ON) temperature coefficient. Low gate charge simplifies gate drive (S)design and minimizes losses.CG EGC 1200V Field Stop E Trench Gate: Low VCE(on) Easy Paralleling CGEApplications: Welding, Inductive Heating, Solar Inverters, SMPS, Motor drives, UPSMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified. ParameterSymbol UNITAPT15GN120BD_SDQ1(G)VCES Co
