APT20GF120BRAPT20GF120BR1200V 32AFast IGBTTO-247The Fast IGBT is a new generation of high voltage power IGBTs. UsingNon-Punch Through Technology the Fast IGBT offers superior ruggedness,fast switching speed and low Collector-Emitter On voltage.G Low Forward Voltage Drop High Freq. Switching to 20KHzCCE Low Tail Current Ultra Low Leakage Current Avalanche Rated RBSOA and SCSOA RatedGEMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified.Symbol Parameter APT20GF120BR UNITVCES Collector-Emitter Voltage 1200VCGR Collector-Gate Voltage (RGE = 20KW) 1200 VoltsVGE Gate-Emitter Voltage 20IC1 Continuous Collector Current @ TC = 25C 32IC2 Continuous Collector Current @ TC = 90C 20AmpsICM Pulsed Collector Current 1 @ TC = 25C 64ILM RBSOA Clamped Inductive Load Current @ Rg = 11W TC = 125C 402EAS S
