Скачать даташит для apt20gn60kg:

apt20gn60kgapt20gn60kg

TYPICAL PERFORMANCE CURVES APT20GN60K(G) 600V APT20GN60KAPT20GN60KG**G Denotes RoHS Compliant, Pb Free Terminal Finish.Utilizing the latest Field Stop and Trench Gate technologies, these IGBT's have ultra low VCE(ON) and are ideal for low frequency applications that require absolute minimum conduction loss. Easy paralleling is a result of very tight parameter distribution and a TO-220slightly positive VCE(ON) temperature coefficient. Low gate charge simplifies gate drive design and minimizes losses. 600V Field Stop Trench Gate: Low VCE(on) Easy Paralleling C 6s Short Circuit Capability 175C RatedGEApplications: Welding, Inductive Heating, Solar Inverters, SMPS, Motor drives, UPSMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified. ParameterSymbol UNITAPT20GN60K(G)VCES Collector-Emitter Voltage600Vo
