APT20GT60KR600V 40AThunderbolt IGBTTO-220The Thunderbolt IGBT is a new generation of high voltage power IGBTs.Using Non-Punch Through Technology the Thunderbolt IGBT offers superiorruggedness and ultrafast switching speed.GC Low Forward Voltage Drop High Freq. Switching to 150KHz EC Low Tail Current Ultra Low Leakage Current Avalanche Rated RBSOA and SCSOA Rated GEMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified.Symbol Parameter APT20GT60KR UNITVCES Collector-Emitter Voltage 600VCGR Collector-Gate Voltage (RGE = 20K) 600VoltsVEC Emitter-Collector Voltage 15VGE Gate-Emitter Voltage 20IC1 Continuous Collector Current @ TC = 25C 40IC2 Continuous Collector Current @ TC = 110C 20Amps1ICM1 Pulsed Collector Current @ TC = 25C 801ICM2 Pulsed Collector Current @ TC = 110C 402E
