BD135 / BD137 / BD139 NPN Plastic Encapsulated Transistor Elektronische Bauelemente RoHS Compliant Product A suffix of -C specifies halogen & lead-free FEATURES TO-126 High current Complement to BD136, BD138 and BD140 1Emitter 1112Collector 2223Base 333CLASSIFICATION OF hFE (1) AProduct-Rank BD135-6 BD135-10 BD135-16 BEFProduct-Rank BD137-6 BD137-10 BD137-16 CNProduct-Rank BD139-6 BD139-10 BD139-16 HLMRange 40~100 63~160 100~250 K DJCollector G2 Millimeter Millimeter REF. REF. Min. Max. Min. Max. A 7.40 7.80 H 1.10 1.50 B 2.50 2.90 J 0.45 0.60 3 C 10.60 11.00 K 0.66 0.86 Base D 15.30 15.70 L 2.10 2.30 E 3.70 3.90 M 1.17 1.37 F 3.90 4.10 N 3.00 3.20 1 G 2.29 TYP. Emitter ABSOLUTE MAXIMUM RATINGS (TA=25C unless otherwise specified) Parameter Symbol Rating Unit BD135 45 B
