Скачать даташит для bd139g_bd135tg_bd135g_bd137g:

BD135G, BD137G, BD139GPlastic Medium-PowerSilicon NPN TransistorsThis series of plastic, medium-power silicon NPN transistors aredesigned for use as audio amplifiers and drivers utilizingcomplementary or quasi complementary circuits.http://onsemi.comFeatures1.5 A POWER TRANSISTORS High DC Current GainNPN SILICON BD 135, 137, 139 are complementary with BD 136, 138, 14045, 60, 80 V, 12.5 W These Devices are Pb-Free, Halogen Free/BFR Free and are RoHSCompliant*COLLECTOR2, 4MAXIMUM RATINGSRating Symbol Value Unit3Collector-Emitter Voltage VCEO VdcBASEBD135G 45BD137G 601BD139G 80EMITTERCollector-Base Voltage VCBO VdcBD135G 45BD137G 60BD139G 100Emitter-Base Voltage VEBO 5.0 VdcTO-225CASE 77-09Collector Current IC 1.5 AdcSTYLE 1Base Current IB 0.5 Adc1Total Device Dissipation PD23@ TA = 25C 1.25 Watt
