Ordering number : ENN6084D CPH3105 / CPH3205PNP / NPN Epitaxial Planar Silicon TransistorsHigh-Current SwitchingCPH3105 / CPH3205ApplicationsApplications DC-DC converters relay drivers, lamp drivers, motor drivers, flash.Features Adoption of FBET, MBIT processes. High current capacitance. Low collector-to-emitter saturation voltage. High-speed switching. Ultrasmall package facilitates miniaturization in end products (mounting height : 0.9mm). High allowable power dissipation.( ) : CPH3105SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO (--50)100 VCollector-to-Emitter Voltage VCES (--50)100 VCollector-to-Emitter Voltage VCEO (--)50 VEmitter-to-Base Voltage VEBO (--)6 VCollector Current IC (--)3 ACollector Current (Pulse) ICP (--)6 ABase Current IB
