Ordering number:EN6073NPN Silicon Epitaxial Planar TransistorCPH3206DC/DC Converter ApplicationsApplications Package Dimensions Relay drivers, lamp drivers, motor drivers, strobes. unit:mm2150Features [CPH3206] Adoption of MBIT processes.2.90.150.4 High current capacitance. Low collector-to-emitter saturation voltage.3 High speed switching.0.05 Ultrasmall-sized package permitting CPH3206-applied sets to be made small and slim (0.9mm). High allowable power dissipation.1 21.91 : Base2 : Emitter3 : CollectorSANYO : CPH3SpecificationsAbsolute Maximum Ratings at Ta = 25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO 15 VCollector-to-Emitter Voltage VCEO 15 VEmitter-to-Base Voltage VEBO 5 VCollector Current IC 3 ACollector Current (Pulse) ICP 5 ABase Current IB 600 mACollecto
