Ordering number : ENA0521 CPH6531SANYO SemiconductorsDATA SHEETPNP Epitaxial Planar Silicon TransistorCPH6531DC / DC Converter ApplicationsApplications Relay drivers, lamp drivers, motor drivers, flash.Features Composite type with two PNP transistors contained in one package facilitating high-density mounting. The two chips contained are equivalent to the CPH3116. Ultrasmall package permitting applied sets to be small and slim.SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO --50 VCollector-to-Emitter Voltage VCES --50 VCollector-to-Emitter Voltage VCEO --50 VEmitter-to-Base Voltage VEBO --5 VCollector Current IC --1.0 ACollector Current (Pulse) ICP --2 ABase Current IB --200 mACollector Dissipation PC Mounted on a ceramic board (600mm20.8m) 1unit 0.9 WT
