CPV362M4FPbFVishay High Power ProductsIGBT SIP Module(Fast IGBT)FEATURES Fully isolated printed circuit board mount package Switching-loss rating includes all tail losses HEXFRED soft ultrafast diodesRoHSCOMPLIANT Optimized for medium speed 1 to 10 kHzSee fig. 1 for current vs. frequency curve Totally lead (Pb)-freeIMS-2 Designed and qualified for industrial levelPRODUCT SUMMARYDESCRIPTIONOUTPUT CURRENT IN A TYPICAL 5.0 kHz MOTOR DRIVEThe IGBT technology is the key to the advanced line of IMSIRMS per phase (3.1 kW total) (Insulated Metal Substrate) power modules. These modules11 Awith TC = 90 Care more efficient than comparable bipolar transistorTJ 125 Cmodules, while at the same time having the simplerSupply voltage (DC) 360 Vgate-drive requirements of the familiar power MOSFET. ThisPower factor 0.8
