PD-5.045BCPV362M4KPRELIMINARYShort Circuit Rated UltraFast IGBTIGBT SIP MODULE1FeaturesFeaturesFeaturesFeaturesFeatures Short Circuit Rated UltraFast: Optimized for high operating frequencies >5.0 kHz , and Short CircuitD1 D3 D5Q1 Q3 Q5 Rated to 10s @ 125C, VGE = 15V3 9 15 Fully isolated printed circuit board mount package4 10 16 Switching-loss rating includes all "tail" lossesD2 D4 D6Q2 Q4 Q66 12 18 HEXFREDTM soft ultrafast diodes Optimized for high operating frequency (over 5kHz)713 19 See Fig. 1 for Current vs. Frequency curveProduct SummaryOutput Current in a Typical 20 kHz Motor Drive4.3 ARMS per phase (1.27 kW total) with TC = 90C, TJ = 125C, Supply Voltage 360Vdc,Power Factor 0.8, Modulation Depth 115% (See Figure 1)DescriptionThe IGBT technology is the key to International Rectifier's advan
