CPV364M4FPbFVishay High Power ProductsIGBT SIP Module(Fast IGBT)FEATURES Fully isolated printed circuit board mount package Switching-loss rating includes all tail lossesRoHSCOMPLIANT HEXFRED soft ultrafast diodes Optimized for medium speed 1 to 10 kHzSee fig. 1 for current vs. frequency curveIMS-2 Totally lead (Pb)-free Designed and qualified for industrial levelPRODUCT SUMMARYOUTPUT CURRENT IN A TYPICAL 5.0 kHz MOTOR DRIVEDESCRIPTIONIRMS per phase (4.6 kW total) 18 ARMSwith TC = 90 CThe IGBT technology is the key to Vishays HPP advancedline of IMS (Insulated Metal Substrate) power modules.TJ 125 CThese modules are more efficient than comparable bipolarSupply voltage 360 Vdctransistor modules, while at the same time having the simplergate-drive requirements of the familiar power MOSFET. ThisPowe
