Скачать даташит для cs10n65fa9hd:

cs10n65fa9hdcs10n65fa9hd

Silicon N-Channel Power MOSFET R CS10N65F A9HD VDSS 650 V General Description ID 10 A CS10N65F A9HD, the silicon N-channel Enhanced PD (TC=25) 50 W VDMOSFETs, is obtained by the self-aligned planar RDS(ON)Typ 0.65 Technology which reduce the conduction loss, improve switching performance and enhance the avalanche energy. The transistor can be used in various power switching circuit for system miniaturization and higher efficiency. The package form is TO-220F, which accords with the RoHS standard. Features Fast Switching ESD Improved Capability Low Gate Charge (Typical Data:39nC) Low Reverse transfer capacitances(Typical:16pF) 100% Single Pulse avalanche energy Test Applications Power switch circuit of adaptor and charger. AbsoluteTc= 25 unless otherwise specified Symbol Parameter Rating Units VDSS Dr
